Zycoo UMTS - Module de UMTS (LTE) 1 puce GSM pour connection data a traver le reseau GSM au Zycoo CoVox U20, U50 et U100

Chargement...

-35%

Module de UMTS (LTE) 1 puce GSM pour connection data a traver le reseau GSM au Zycoo CoVox U20, U50 et U100 UMTS

Quantité

Ajouter au panier

Ajouter à ma sélection

Prix Normal : 3 478,80 Dh TTC

Prix :2 639,88 Dh TTC

Prix Promo : 2 243,90 Dh TTC

Hors Taxe : 1 869,92 Dh HT

Economie : 205,82 Dh - 35%

UMTS LTE module pour 3G WCDMA data access pour les IPBXs CoVox (U20/50/100)

Disponibilité : En Stock

Evaluation :

Evaluer ce produit.

Description
Téléchargements
Avis des clients

Description

UMTS module for 3G WCDMA data access(For U20/50/100)

The GSM module supports CooVox-U20 IP Phone System for GSM connection. Each port has one LED(Light-Emitting Diodes).

Designed with SIM900 for global market, SIM900 is a quad-band GSM engine that works on frequencies GSM 850MHz, EGSM 900MHz, DCS 1800MHz and PCS 1900MHz.

Fiche Technique

The GSM module supports CooVox-U2 Ip Phone Systemfor GSM connection. Each port has one LED(Light-Emitting Diodes), which is assembled on the mainboard.
The Red LED indicates port status:
 Solid Red= Module loading successful
 Blink Red= Channel Ringing
If the LED is off, the GSM module is loading failure.

The Red LED indicates port status:
 Solid Red= TE Model
The Green LED indicates port status:
 Solid Green= NT Model
If the LED is off, the module is loading failure.

SIM900 key features

Feature	Implementation
Power supply	Single supply voltage 3.4V-4.5V
Power saving	Typical power consumption is SLEEP mode is 1.5mA(BS-PA-MFRMS=5)
Frequency Bands	SIM900 quad-band:GSM850, EGSM 900, DCS 1800, PCS 1900. The SIM900 can search the 4 frequency bands automatically. Compliant to GSM Phase 2/2+
GSM class	Small MS
Transmitting power	Class 4(2W) at GSM 850 and EGSM 900 Class 1(1W) at DCS 1800 and PCS 1900
Temperature range	Normal operation: -30-+80 degrees Centigrade
